Model 6600 PLUS TLD Card Reader Instrument (with Built-in Internal 90Sr/Y Irradiator for the 6600 PLUS)

Major Functions / Key Features

• A TLD reader system for reading TLD cards
• Can read both LiF: Mg, Ti and Lif: Mg, Cu, P types of TL materials
• Built-in automatic dosimeter calibration capability
• Extensive built-in automatic QC tests & high MTBF
• No requirement for a separate extremity system
• Flat Panel display and touchscreen operation
• Exceeds IEC, ISO and ANSI performance requirements
• Built-in WinREMS software
• Dynamic range: seven decades linear – extended high range with optional neutral density filters
• Capacity: 200 personnel/ environmental or 400 EXTRAD or 800 DXTRAD extremity dosimeters per loading
• Radiations measured: Photons, energies >5 keV; Neutrons, from thermal to fast; Betas, energies >70 keV
